Flange Adaptor

Flange Adaptor
Product name:Flange Adaptor
Item:
Details:
Ductile Iron Pipe Line Universal Flange Adaptors



Working Pressure:

Working pressure: PN10, PN16



Parts & Materials:

Sleeve

Ductile iron

Gland/End Ring

Ductile iron

Gasket

EPDM, SBR

Bushing

Bronze

Bolt/Nut

Carbon Steel, electro galvanized

Washer

Carbon Steel, electro galvanized

Coating

Fusion Bonded Epoxy (FBE)



Dimension:



Size

OD(Range)

PCD

Flange

Holes

Bolt Holes on Gland

Suitable for PIPES

DN50

59-72

125

8-19

4-14

UPVC

DUCTILE IRON PIPE

STEEL PIPE

DN65

72-85



8-19

4-14

DN80

88-103

160

8-19

4-14

DN100

108-128

178.5

8-19

4-14

DN125

132-158

210

8-19

4-14

DN150

158-182

237.5

12-23

4-14

DN175-200

189-212

295

12-23

6-14

DN200

218-235

295

12-23

6-14

DN225-250

244-276

355

12-23

6-14

DN250

271-289

355

12-28

6-14

DN300

322-350

410

12-28

6-14





Ductile Iron Pipe Line Universal Flange Adaptors
